Salient Features of Utari Dam
Work Done Value - (Rs. in Cr.) 33.50
Completed Month/Year : Dec-2012
Location of proposed Utari Dam
- Project Name: Const. of Spillway of Utari Dam.
- District : Lalitpur
- Tehsil : Lalitpur
- Source River : Utari
- Catchment area : 7834 Sq. Kms.
- Storage Capacity : 46.0 MCM
Type : Earth Dam
- Length : 470 M.
- Maximum height : 19.35 M.
- Crest Level : 188.930 M.
- F.R. L. : 195.930 M.
- H.F.L. : 198.670 M.
- Top of Dam : 200.67 M.
- Nos. & Size of gate : 15 Nos. 18.0M X 7.3M.
- Pier width : 2.5M.
- Clear water way : 270M.
- Design flood (Proposed) (on hundred years return period ) : 19500 cumecs.
Afflux Bund
Location of proposed Utari Dam
- Length of right afflux Bund : 2.178 M.
- Length of Left afflux bund : 7.00km.
- Top of Bund (W.R.T. MFL) : 01 March, 2020
- Culturable command Area : 46,485 Hect.
Proposed Irrigation
- Kharif : 14,575 Hect.
- Rabi : 31,910 Hect.
- Cost of Project : 7667.95 Lac.
- B.C. Ratio : 2.6 : 1
History and introduction
It is understood and agreed that the contractor has satisfied himself as to the nature and location of the works, general and local conditions and particularly those bearing on transport, handling or storage of materials, disposal of spoils, availability of labour, weather conditions or similar physical conditions at the work site subsoil water, hydrology the configuration of ground the character quality and quantity or the surface and the sub0surface materials to be encountered. The character of equipment and facilities needed preliminary to and during the execution of the work and all other matters which may in any way affect the work or the cost thereof under this contract.
